2 Overview of the display
1
2
3
4
5
6
7
8
9
11
10
Fig. 2.1 Overview of the display
Key
1 Installer level and
Service/Diagnosis level (Chapter 11.1)
2 Info level (see 4.7)
3 Hot water symbol
4 Circulation pump symbol
5 Heating circuit symbol
6 Time/temperature display
7 Days of the week
8 Actual temperature
9 Operating modes (see 4.1)
10 Special functions (see 4.6)
11 Setting timer programmes (see 4.3)
