45GBInstallation instructions VRT 360f
13 Technical data
Description Unit Sender Receiver
Operating voltage V 3V (2xAAA) 24
Maximum permissible ambient temperature °C 50 50
Battery working life Months approx. 18
Transmission frequency MHz 868,35 868,35
Transmission capacity mW 0,5
Current consumption mA
≤ 0,4 (readiness) ≤ 12 (readiness)
Minimum cross-section of the connection lines mm2 0,75
Level of protection IP 20 IP 20
Protection rating for regulator III III
Dimensions
Height/width/depth mm 97/146/27 97/146/27
Table 13.1 Technical data
Technical data 13
