3. A setup wizard starts when AP10 is first powered up. Use the touch interface to complete
the wizard:
a. Select a language for the touchscreen display.
b. Configure the network settings so that AP10 can join the network:
• Select Dynamic IP address (DHCP) if you are connecting the access point to a
network that assigns network configuration settings automatically.
• Select Static IP address to configure network settings manually. Using the
information supplied by your IT administrator, enter the IP address, Subnet mask,
and Default gateway.
DHCP is the most common way to assign network settings. Do not use a
static address unless your IT administrator has instructed you to do so.
c. Configure the Network Time Protocol (NTP) servers that the access point will attempt
to synchronize with. If you have a local NTP server in the network, replace one of the
default NTP server hostnames with its IP address or hostname.
d. Select a VaiNet channel (1 ... 8). Each access point in range of each other must have a
unique channel assigned to it.
e. Enter the IP address or hostname of the viewLinc Enterprise Server. Leave the TCP
port at default 12600 unless you know it has been changed.
f. Enable Installation Mode to start connecting data loggers to your system.
g. Wait for the display to change to the home screen.
4. If the setup wizard has already been completed previously, press the symbol to open
the Settings screen and check all of the settings listed in step 3. There are also some
optional settings for display and LED, and for locking the touchscreen using a password.
The default password is ap123456.
6 M211821EN-E
