Val Controls IHP24-A Hardware Manual

DHW-UM-002
Val Controls A/S • Limfjordsvej 3 • DK-6715 Esbjerg N • Tel. +45 7547 0600
vc@valcontrols.com • www.valcontrols.com
Revision: 3
13/20
4.2 Digital input – DI12
DI12 substitutes AI0
Switch
1
DI12
5
+ -
1kΩ ½W
2 6
The external resistor and connection between terminal 2 and 6 must be mounted to get the correct
functionality.
4.2.1 Terminals
DI12
1 (+)
5 (-)
4.2.2 Electrical specifications
DI12
Type
Switch
Cable length
1000 meters
