1 General
This manual covers the following products:
IHP24-A
IDP24-A with software DID-SW-001
IVC24-A
IDC24-A
ILB24-A
ILC24-A
IPC24-A
1.1 Safety instructions
For a safe installation of a Val Controls device, the following must be observed. The module must
be installed by qualified personnel who are familiar with the national and international laws,
directives and standards that apply to this product as well as all instructions in this manual.
The information in this manual is subject to changes without notice.
1.2 Environment
Operating temperature: -30 to 80 ˚C
Storage temperature: -30 to 80 ˚C
Extended operating temperature
1
: -40 to 85˚C
Extended storage temperature
1
: -55 to 100˚C
1
Please contact Val Controls
Relative Humidity: < 95% (No condensation)
The printed circuit boards are coated for tropical climate and harsh environments to resist airborne
contamination according to G3, ISA-71.04-2013.
Ingress protection: IP20
1.3 Mounting and dimension
Mounting: 35mm DIN rail according to EN50022.
Screw torque: 0.4Nm (3.6Lb. in)
Wire diameter: 28-12 AWG 2.5mm
2
All external components must have specifications that fit the desired performance and requirements
of the valve/actuator system.
Dimensional drawing can be found on www.valcontrols.com
