Val Controls IHP24-BF User Manual

DHP-UM-013
Val Controls A/S • Limfjordsvej 3 • DK-6715 Esbjerg N • Tel. +45 7547 0600 • Fax +45 7547 0611
vc@valcontrols.com • www.valcontrols.com
Revision: 4
38/58
Value: uninitialized
Description: Determines if the values passed by the
transducer block to the AI block may be used directly
“Direct” or if the valu is in different units and must
be converted linearly “Indirect” or with square root
“Ind Sqr Root” using input range defined for the
transducer block.
LOW_CUT
[Tuning]
17
Length 4 byte
Read Write
Value: 0
Description: Limit used in square root processing. A
value of zero percent of scale is used in block
processing if the transducer value fails below this
limit in % of scale: This feature may be used to
eliminate noise near zero from a flow sensor.
PV_FTIME
[Tuning]
18
Length 4 byte
Read Write
Value: 0 sec
Description: Time constant of a single exponential
filter for the PV in seconds
FIELD_VAL
[Process]
[Trends]
19
1: Value
Length 4 byte
Read Only
Value: 0
2: Status
Length 1 byte
Read Only
Description: Raw value of the field device in % of
PV range.
UPDATE_EVT
[Others]
20
1 Unacknowledged:
Length: 1 bytes
Read Write
2 Update State:
Length: 1 bytes
Read Only
3 Time Stamp:
Length: 8 bytes
Read Only
