5
Overview of the appliance
A
Installation
Installation of the oven
• The oven must be positioned in a dry, airy space
with good ventilation. The position of the oven
should ensure free access to its touch-control
keys.
•
The finishing and adhesive materials used to
house the oven, must be able to withstand a
temperature of 100 °C. If these conditions are
not met, the surface finish or coating of the units
may warp.
•
Cut out an area in the housing unit as per the
dimensions shown on the diagram.
• Fully insert the oven into the recess and secure
using four screws (as shown in the drawing) to
prevent it from moving.
EN
595
560
560
40
560
560
006
83.nim
min. 600
