Valcom V-2924A User Manual

2
The V-2924A Control Unit provides access to 24 stations. A V-2925A Expansion Unit is available for the
V-2924A. Each V-2925A Expansion Unit will increase the capacity of the V-2924A by twenty-four (24) additional
stations. Up to three (3) Expansion Units can be added to a system for a total of 48, 72 or 96 zones of paging.
A V-2926 Plug-in Option Board is also available to provide enhanced Caller ID, flexible architectural numbering,
user defined page groups, a secondary serial port for easier programming and real-time clock. A Windows-based
programming tool is used with the option board to simplify system programming. The tool can be used with PC
compatible computers using the Microsoft Windows operating system.
“WARNING: To reduce the risk of fire or electric shock, do not expose this appliance to rain or
moisture.”
“WARNING: Shock Hazard – Do Not Open.”
“AVIS: Risque de choc Electrique ne pas Ouvrir.”
“PELIGRO: Corriente Electrica – No Abres.”
FEATURES
• 24 zones of handsfree or one-way
communication (expandable up to 96 zones)
• Built-in handsfree amplifier
• Background music input
• Built-in all call with "meet me" and "follow me"
capability
• "Ring in" from speaker locations
• Calls placed in queue
• Dial tone programmable (On/Off)
• Alert tone
• Ringback tone
• Repeated alert/privacy tone programmable
(On/Off)
• Auxiliary contact closures for zones 21, 22, 23,
24
• Programmable ring pattern
• Ring contact closure follows ring cycle
• Inhibit input
• Caller identification
• RS-232 serial printer port
• Control unit is internally powered (battery
backup compatible; (1) VPB-260 per unit)
• Override port
• Emergency tone input
• Time tone input
• UNA contact closure input
• All call/priority page through up to six V-2924A
systems of any size
• Group call
• Programmable class of service
CAPACITY
• The V-2924A is a single talkpath unit.
• The maximum number of speakers per zone:
one 45 Ohm speaker and/or forty (40) one-way
amplified speakers.
NOMINAL SPECIFICATIONS
These units are not intended for direct or indirect
connection to the public telephone network. When
used with a customer premise telephone system such
as a key system or PABX system, these units are
interfaced to the system via a fully protective paging
port or a system central port, which are fully
protected interface devices. Additionally, the host
system must be configured to disallow a central
exchange trunk conferencing in order to prevent
indirect connection to the network.
Attendant Port
• Loop Start Access (E-Key C. O. Line Position,
Single Line Phone, Trunk Port of PABX)
• DTMF Access
• Caller ID Compatible
• Tip and Ring Input Impedance: 600 Ohms
• Tip and Ring Input Level: -10dBm nominal
Ring Supply
90VAC, 30Hz - Ring Patterns:
2 sec ON, 4 sec OFF: American
1 sec ON, 4 sec OFF: Dutch
Double Ring: British
Override Page Port
• Loop Start Access (E-Key C. O. Line Position,
Single Line Phone, Trunk Port of PABX)
• Telephone System Page Port Access
• Tip and Ring Input Impedance: 600 Ohms
• Tip and Ring Input Level: -10dBm nominal

Valcom V-2924A Specifications

General

Brand	Valcom
Model	V-2924A
Category	Intercom System
Language	English
