User Programming - Basic System
Table 1 – Dip Switch Options for Switches SW1 - SW4:
(Shaded areas indicate default values - Unit power source must be removed before altering dip switch settings)
Switch OFF Switch ON
Main Board SW2
SW2-1
Station 21 call button NORMAL priority Station 21 call button LOW priority
SW2-2
Station 22 call button NORMAL priority Station 22 call button LOW priority
SW2-3
Station 23 call button NORMAL priority Station 23 call button LOW priority
SW2-4
Station 24 call button NORMAL priority Station 24 call button LOW priority
SW2-5
2 digit dialing plan
3 digit dialing plan
SW2-6
No queue tone to speaker/attendant
Queue tone to speaker/attendant
SW2-7
No dial tone to attendant
Dial tone to attendant
SW2-8
No handsfree alert tone to speaker
Handsfree alert tone to speaker
Main Board SW3
SW3-1
No 1-way page alert tone to speaker
1-way page alert tone to speaker
SW3-2
No ringback tone to Attendant
1
(HF or group page)
Ringback tone to attendant
(HF and group page)
SW3-3
No 15 second privacy tone to HF speaker
15 second privacy tone to HF speaker
SW3-4
Priority phone controls local V-2924A only
Priority phone controls all connected V-2924As
SW3-5
External priority blocks local priority Local priority overrides external priority
SW3-6
(see "Ringing Pattern Options" table below)
SW3-7
(see "Ringing Pattern Options" table below)
SW3-8
Use internal time and emergency tones Use V-9927A for time and emergency tones
1
Tone will be heard regardless of SW3-2 setting if SW2-8 or SW3-1 is turned on
Ringing Pattern Options
SW3-6 SW3-7
American
OFF OFF 2 seconds ON, 4 seconds OFF
Dutch
OFF ON 1 second ON, 4 seconds OFF
British
ON OFF Double ring burst, x seconds OFF
Background Music Options
Switch OFF Switch ON
Main Board SW1
SW1-1
No BGM to group 1 BGM to group 1 Stations 1 - 6
SW1-2
No BGM to group 2 BGM to group 2 Stations 7-12
SW1-3
No BGM to group 3 BGM to group 3 Stations 13-18
SW1-4
No BGM to group 4 BGM to group 4 Stations 19-24
Override Port Options
Switch OFF Switch ON
Main Board SW4
Tel. System Page Port Access
Loop Start Trunk Port
