Valcom V-2924A - Inhibit Option; External Tone Source (ex.V-9927 A); SMDR Printer Port Cable

8
26
1
37
12
W/BL T
BL/W R
BK/O
O/BK
Inh.
Inh.
Tel.Sys. C.O. Line
position or single
line telephone
Dedicated "Meet
Me" Telephone
T R A A1
5.1K Ohm
INHIBIT OPTION
P7 Connecting Block
P7 Connecting Block
30
5
32
7
34
9
Signal
Out
V-9927A
(1-8)
Com
EXTERNAL TONE SOURCE USING A V-9927A
*NOTE: External tone source requires dip switch settings to enable
feature. See Table 1(SW3-8)
W/S
S/W
R/O
O/R
R/BR
BR/R
31
6
33
8
Control
from time
clock
Emergency
Closure
Normally
Open Switch
22
33
57
DB9 Female
DB25 Male
To P10
V-2924A
Control
Unit
Baud Rate 9600, 8 bit, no parity, 1 stop bit
SMDR PRINTER PORT CABLE
