3
HIGH VOLTAGE AREA
DISCONNECT POWER
BEFORE SERVICING
J1
JP2
Option
Board
Location
Align J3 on the Option Board directly over J1 on the Control Board
Align J4 on the Option Board directly over JP2 on the Control Board
Press Option Board firmly into place.
FIGURE 1 - OPTION BOARD LOCATION ON THE V-2928 CONTROL BOARD
Side View
Top View
P10
P1
RS232 Serial Port
for SMDR (DB9
Connector)
PC Programming
Port (located on
Option Board)
Slide plate covering
connector ports up
to provide opening
for connector
J3 and J4 are located on the
under side of the Option Board.
