valent VX Series Reference Guide

Valent VX Series Controller 49
VARIABLE DESCRIPTION
ACTIVE
TEXT
INACTIVE
TEXT
BACNET MODBUS
OBJECT
INSTANCE
OBJECT
TYPE
ACCESS HYST INDEX
REGISTER
TYPE
SIZE
Binary Values - Read Only
Occupied Occupied Status. Occupied
Unoccupied
16 BV
ReadCOV_
NoWrite
0 10002 Discrete
Unoccupied Unoccupied Status. Unoccupied Occupied 17 BV
ReadCOV_
NoWrite
0 10003 Discrete
Unoccupied_Cooling_
Call
Unoccupied Cooling Call
Status
Active Inactive 18 BV
ReadCOV_
NoWrite
0 10004 Discrete
Unoccupied_
Dehumidification_Call
Unoccupied
Dehumidification Call
Status
Active Inactive 19 BV
ReadCOV_
NoWrite
0 10005 Discrete
Unoccupied_Heating_
Call
Unoccupied Heating Call
Status
Active Inactive 20 BV
ReadCOV_
NoWrite
0 10006 Discrete
Occupied_Start
Occupied Start Command
Status
Active Inactive 21 BV
ReadCOV_
NoWrite
0 10007 Discrete
Unoccupied_Start
Unoccupied Start Command
Status
Active Inactive 22 BV
ReadCOV_
NoWrite
0 10008 Discrete
Enable_Controls
Status to indicate startup
is complete and the unit is
ready.
Enabled Disabled 23 BV
ReadCOV_
NoWrite
0 10009 Discrete
Global_Alarm
General alarm point.
Optionally set to indicate
any alarm is active, or a
shutdown alarm is active.
Alarm Normal 24 BV
ReadCOV_
NoWrite
0 10010 Discrete
System_Shutdown_
Alarm
Shutdown alarm status.
When true, System Enable
will be set to false and the
unit will remain off.
Shutdown Normal 25 BV
ReadCOV_
NoWrite
0 10011 Discrete
Damper_Open
Indicates there is a open
air path and the supply fan
can run.
Open Closed 26 BV
ReadCOV_
NoWrite
0 10012 Discrete
Cooling_is_On
Indicates that the unit is
cooling.
Active Inactive 27 BV
ReadCOV_
NoWrite
0 10013 Discrete
Economizer_is_On
Indicates that the unit is
economizing.
Active Inactive 28 BV
ReadCOV_
NoWrite
0 10014 Discrete
Heating_is_On
Indicates that the unit is
heating.
Active Inactive 29 BV
ReadCOV_
NoWrite
0 10015 Discrete
Dehumidification_
Mode_Enabled
Indicates that the unit is
dehumidifying.
Active Inactive 31 BV
ReadCOV_
NoWrite
0 10017 Discrete
Manual_Override_
Active
Indicates that manual
overrides are active.
Override Normal 32 BV
ReadCOV_
NoWrite
0 10018 Discrete
Cooling_Not_Locked_
Out
Indicates that cooling is
allowed.
Allowed
Locked_
Out
33 BV
ReadCOV_
NoWrite
0 10019 Discrete
Heating_Not_Locked_
Out
Indicates that heating is
allowed.
Allowed
Locked_
Out
34 BV
ReadCOV_
NoWrite
0 10020 Discrete
Preheat_Not_Locked_
Out
Indicates that preheat is
allowed.
Allowed
Locked_
Out
36 BV
ReadCOV_
NoWrite
0 10022 Discrete
HGRH_Purging
Indicates that the hot gas
reheat value is purging.
Active Inactive 37 BV
ReadCOV_
NoWrite
0 10023 Discrete
Allow_Dampers
Startup sequence command
to open dampers
Yes No 43 BV
ReadCOV_
NoWrite
0 10029 Discrete
Allow_Exhaust_Fans
Startup sequence command
to trigger exhaust fans to
start
Yes No 44 BV
ReadCOV_
NoWrite
0 10030 Discrete
Allow_Supply_Fans
Startup sequence command
to trigger supply fans to
start
Yes No 48 BV
ReadCOV_
NoWrite
0 10034 Discrete
BMS_Watchdog_Active
Status of the BMS
watchdog ping.
Active Inactive 49 BV
ReadCOV_
NoWrite
0 10035 Discrete
BMS_Occupancy_
Status
Status of the BMS
occupancy command.
Occupied
Unoccupied
50 BV
ReadCOV_
NoWrite
0 10036 Discrete
Compressor_1_
Enable_Digital_Output
Compressor 1 Enable
Digital Output
Active Inactive 111 BV
ReadCOV_
NoWrite
0 10164 Discrete
Compressor_2_
Enable_Digital_Output
Compressor 2 Enable
Digital Output
Active Inactive 112 BV
ReadCOV_
NoWrite
0 10165 Discrete
Compressor_3_
Enable_Digital_Output
Compressor 3 Enable
Digital Output
Active Inactive 113 BV
ReadCOV_
NoWrite
0 10166 Discrete
Appendix E: Points List
