Thermo plus 160/230/300/350 6 Wiring diagrams
6 Wiring diagrams
6.1 General
The following figures represent heater connection options
to the vehicle electrical system.
The minimum cable cross-sections indicated in the table
must be applied.
* The cable cross-section is to be reduced in front of the
heater to 2.5 mm².
NOTE:
The vehicle type fuses are to be installed so, that their
ambient temperature do not exceed 60°C.
Cable length <7.5m Cable length 7.5 - 15m
0.75 mm² 1.5 mm²
2.5 mm² 4.0 mm² *
