8- Service tools
Unless otherwise specified,
the edges to be slight chamfering.
Should remove burrs and fluff.
Part Name
3rd Angle Proj.
Surface Treatment
Heat Treatment
& Hardness
Material
Br
- -HQF - HTL
HRC40 to 45
3
1
2
SS41 SS41 S45C
1 2 3
Armature Holder
Material
Bolt
Collar
Part Name
Material
Heat Treatment
& Hardness
Surface Treatment
3rd Angle Proj.
Assy
1
2
1
2
Armature Installer Assy
