Valeo TM55 - 9 Service Parts

- 47 -
9- Service parts
Item* Part name Reference Quantity
O-RING SET Z0014430 -
12 O-ring body (front & rear head) Z0004833 n=2
20 O-ring drain 569300-4000 n=1
SHAFT SEAL (for service) - -
11 Shaft seal Z0007461 n=1
1. Compressor body service kits, sets and parts
*See Product description - Exploded view (p.10)
Item* Part name Reference Quantity Remarks
24 Connector (body) Z0011223 n=1 Dis./Suc.
23 Gasket Z0011226 n=1 For conn.
26 Gasket Z0011227 n=1 For piping
25 Bolt Z0011228 n=2 For conn.
Item Part name Reference Quantity
- ZXL 100PG (250 cc) 569900-0600 250 cc
2. Connector assy (Z0011222) service parts
3. Oil
*See Product description - Exploded view (p.10)
