Valeo TM55 - Page 48

- 46 -
8- Service tools
Unless otherwise specified,
the edges to be slight chamfering.
Should remove burrs and fluff.
Part Name
3rd Angle Proj.
Surface Treatment
Heat Treatment
& Hardness
Material
S45C
Br
(57)
(18)
Ø16
C1.0 M16X2.0 (2)
Ø10
30°
(12)
(13.9)
Ø7
Ø10.5
R2
(152)
R1.5
(35) (42)
R
- -HQ - HQf
HRC40 to 45
Armature puller assy
2
Pole
Unless otherwise specified,
the edges to be slight chamfering.
Should remove burrs and fluff.
Part Name
3rd Angle Proj.
Surface Treatment
Heat Treatment
& Hardness
Material
S45C
Br
(13.9)
(12)(9) (30) (7) (30)
(20)
(96)
(10/1)
M12X1.75M6X1.0
Ø9.5
C1.0
Ø10
Ø10
30°
A
Ø5
Ø9.5
(0.5)
R1.5
45°
(0.5)
(7)
A section detailed view
Armature puller assy
3
Bolt
