Valeo TM55 User Manual

- 3 -
1- 1- Product description
MODEL
TM55 TM65
TECHNOLOGY Heavy Duty Swash Plate
DISPLACEMENT 550 cc / 33.56 in
3
per rev. 635cc / 38.75 in
3
per rev.
NUMBER OF CYLINDERS 14 (7 double-headed pistons)
REVOLUTION RANGE 600-4000 rpm
DIRECTION OF ROTATION Clockwise viewed from clutch
BORE 38.5 mm (1.52 in)
STROKE 33.7 mm (1.30 in) 38.9 mm (1.53 in)
SHAFT SEAL Lip seal type
LUBRICATION SYSTEM Lubrication by gear pump
REFRIGERANT HFC-134a
OIL (QUANTITY) ZXL 100PG PAG OIL (1500 cc/0.40 gal) or POE option
CONNECTIONS
Internal Hose Diameter
Suction: 35 mm (1-3/8 in)
Discharge: 28 mm (1-1/8 in)
Suction: 35 mm (1-3/8 in)
Discharge: 35 mm (1-3/8 in)
WEIGHT 18.1kg / 39.9 lbs (w/o Clutch)
DIMENSIONS
Length - Width - Height
341 - 194 - 294 (mm)
13.4 - 7.64 - 9.33 (in)
MOUNTING Direct (side or base)
Compressor
Valeo TM55 & TM65 Application limits
- Compressor
Saturated evaporating conditions
t
c
t
e
Saturated condensing conditions
PSIA PSIG
o
F MPaA MPaG
o
C
398 384 180 2.75 2.65 82
244 229 140 1.68 1.58 60
125 111 93 0.86 0.76 34
83 68 68 0.57 0.47 20
-20 -10 10 20
o
C
0.03 0.10 0.31 0.47 MPaG
0.13 0.20 0.41 0.57 MPaA
-4 14 50 68
o
F
5 14 45 68 PSIG
19 29 60 83 PSIA
t
c
: Condensing temperature
t
e
: Evaporating gas temperature
