- 45 -
8- Service tools
Part Name
3rd Angle Proj.
Surface Treatment
Heat Treatment
& Hardness
Material
1
2
3
Plate
Pole
Bolt
1
2
3
Armature Puller Assy
Unless otherwise specified,
the edges to be slight chamfering.
Should remove burrs and fluff.
Part Name
3rd Angle Proj.
Surface Treatment
Heat Treatment
& Hardness
Material
S45C
Br
Ø70
(15)
6-M12X1.75
PCD50±0.1
M16X2.0
2-C1.0
12-C1.0
2-C1.0
6-60°±0.1°
Armature puller assy
1
Plate
