Valeo TM55 - Page 46

- 44 -
8- Service tools
14
-0.25
16.2( )
206029
±0.5
7Ø
2R
5
1R
Armature Puller
Part Name
3rd Angle Proj.
HQ-HQf
HRC40 to 45
S45C
Heat Treatment
& Hardness
Surface Treatment
Material
Unless otherwise specified,
the edges to be slight chamfering.
Should remove burrs and fluff.
Br
M12x1.75
1C
