BCs160VA
Nov. 15, 1997
SMART-PULP Smart Consistency Transmitter
41
Pulp types corresponding to the codes (A, B,...) are specified in the appended table.
Figure 7.1b Flow velocities/consistency ranges/pulp types for different sensor options (cont. on next page)
SMART-PULP UL
(1)+(2): For pulps A, B, F, G and L
(1): For pulps C, D and J
For pulp E (and L)
For pulp K
SMART-PULP LL
SMART-PULP LS
(1)+(2): For pulps A and B
(2): For pulps C and D
(1): For pulp G
(1)+(2): For pulp L
For pulps F and G
