Valmet SMART-PULP - Page 42

BCs160VA
Nov. 15, 1997
SMART-PULP Smart Consistency Transmitter
42
Pulp types corresponding to the codes (A, B,...) are specified in the appended table.
Figure 7.1b Flow velocities/consistency ranges/pulp types for different sensor options
(cont. from previous page)
SMART-PULP RL
For pulps A and B (1)+(2): For pulps C and D
(1): For pulps E and F
(1)+(2)+(3): For pulp J
(1)+(3)+(4): For pulp K
(1)+(2): For pulp L
SMART-PULP GL SMART-PULP WS
(1)+(2): For pulps A and B
(1): For pulp G
(1)+(2): For pulps C, D, E
(1): For pulp F
(1)+(2)+(3): For pulps J and K
For pulps H and I
