5. Install the 12 loose coals as follows. The
underside of each coal is marked with a letter
‘A’ to ‘L’ and an arrow.
6. The coals should be positioned so that the
arrows always point towards the back of the
firebox. When located into position the stem of
each arrow should be at 90° to the rear of the
firebox
7. Hold coal ‘A’ upright with the arrow
pointing to the top. Locate coal ‘A’ as shown
in figure 6.
8. . Locate coals ‘B’ to ‘E’
so that they are firmly seated
in the valleys in the coal
base and front coal.
9. Hold coal ‘B’ upright
with the arrow pointing to
the top. Locate coal ‘B’ as
shown in figure 7.
10. Hold coal ‘C’ upright
with the arrow pointing to
the top. Locate coal ‘C’ as
shown in figure 8.
Figure 8. Second row “Coal C”
Figure 7. Second row “Coal B”
Figure 6.Front Row “Coal A”
