Valor C1

OWNER’S GUIDE
PAGE 14
15. Locate coals ‘G’ to ‘K’ so
that they are firmly seated in the
valleys in the coal base.
16. Hold coal ‘G’ upright with
the arrow pointing to the top.
Locate coal ‘G’ as shown in
figure 12.
17. Hold coal ‘H’ upright with
the arrow pointing to the top.
Locate coal ‘H’ as shown in
figure 13
18. Hold coal ‘I’ upright with
the arrow pointing to the top.
Locate coal ‘I’ as shown in
figure 14.
Figure 14. Third row “Coal I”
Figure 13. Third row “Coal H”
Figure 12. Third row “Coal G”
