597
Model
No Page
1(4)6000---8400 39.3FITTING INSTRUCTION
SPEEDOMETER AND CLOCK
10.06.1994
14.04.1998
Speedometer and clo ck 32635700.........
Fitting:
--- Speedometer and clock are fitted in their casing
on the instrument panel.
--- Detach the instrument panel, fit the casing and
mark places for holes and lead---in points for
wires.
--- Drill holes (ø 5mm, 2 pcs ) for fixing screws and
a hole ø 32mm for wires (connector, 9 pins).
--- Fasten the casing with screws 3 (2 pcs) and
fasten the display unit into the casing.
--- Detach the RH side threshold moulding and the
side panel. Draw the wire loom 4 backwards
under the floor mat.
--- Carry out wire connections according to the pic-
ture:
--- wire no 1 (red) to connector X2 pin 2. Con-
nector is placed in the fuse box.
--- wire no 2 (yellow) to connector X3 pin 7. Con-
nector is placed in the fuse box.
--- earth wire under the earth screw 5.
--- Fit the wheel sensor bracket 6 under the nut of
the LH side check link. Nut is fitted under the
rear axle housing. Fit the sensor and connect
wires to the 3---pin connector. Blue wire to pin 1
and brown to pin 3.
--- Change two rear wheel attaching bolts with
bolts fitted with magnet (bolts which fitted 180˚
opposite each other). Yellow dot on magnets
against the sensor. Secure screws with Loctite
242.
--- Adjust distance between sensor and magnet to
1 --- 5m m .
1 32635700 Nop.mitt. ja kello Hastig.m.+klocka S.meter+clock Tachometer+Uhr
1 1 32663710 .Näyttölaite Teckenförster Display unit Bildschirm
2 1 32663500 .Kotelo Hus Housing Gehäuse
3 2 HD4313 .Ruuvi Skruv Screw Schraube
Vis (M6x12)
4 1 32663600 .Johdin Ledning Wire Leitung
5 1 31703200 .Anturi Givare Sensor Geber
6 1 31703300 .Kannatin Hållare Support Halter
7 2 HE6958 .Ruuvi Skruv Screw Schraube
Vis
8 2 31720500 .Magneetti Magnet Magnet Magnet
9 2 31720600 .Aluslaatta Bricka Washer Scheibe
10 2 32249200 .Ruuvi Skruv Screw Schraube
Vis
