FITTING INSTRUCTION 39.4 1(3)
ROTATING WARNING LIGHT
6000---8750
08.12.1995
14.04.1998
Rotating warning light (on LH side) 31687000..
(mounting on RH side) 31983500..............
for model LS 32952400......................
Rotating warning light
(blue) 33361200.......
The light is fitted on the handle on the cab LH side
front corner according to the picture.
Fitting
:
--- Fasten the light bracket using fasteners 6 (4pcs)
and screws 7 (see picture).
--- Connect the supply and earth wire no 9 to the light
(picture A). Push the plastic shield of the wire
through the hole on the tube 4.
Connect the other end of the wire to connector X22
in the cab wire loom. Connector is placed in the LH
side front corner under the visor (picture B).
--- Up to the cab no 470 the supply wire (no 117 red)
can be found by opening a little the rear roof edge
in the middle. The wire is connected with an exist-
ing lead to the direction indicator. Place the wire
undertheLHsideedgesealoftheroof.
--- Fit the rotating warning light into the socket 3 and
tighten the wing nut.
Instrument panel:
--- Open the panel cover by unscrewing 4 st cross---
head screws and the ignition switch nut.
--- Remove the covering and fit the rocker switch 12.
--- Connect existing connector S6 in the wire loom
(wires no 117 and 79) to the rocker switch and
wires no 26 and the earth wire (white) to the indi-
cating lamp holder (picture C).
