605
Model
No Page
6000---8750 39.5
RADIO, FITTING INSTRUCTION
1
05.09.1994
01.06.1998 (3)
Radio/cassette
(CLARION ARB---1370E) 32830540...............
Radio is fitted into the console in the roof (PT94---
cabs: on the right side of the roof) and loudspeakers
into the rear part of the cab roof (see pictures).
Fitting:
--- The loudspeakers and the antenna and their wires
must be fitted before fitting the radio.
Cabs to the end of the year 1993:
Remove knobs and switches from the roof panel
and remove the panel (8 pcs cross---head screws).
PT94-- cabs: remove with e.g a hack saw the shi-
eld for opening.
Loudspeakers (picture A, B, C):
--- Cabs to the end of the year 1993: Cut holes in the
roof lining in points for loudspeakers. Hole diam-
eter is about 104 mm.
PT94-- cabs: Remove the protective net.
--- Draw loudspeaker wires between the roof lining
and the outer roof plate using a suitable wire.
--- Connect wires in a correct way, -- and + wires to
the correct pins and fasten the loudspeakers using
screws and spring washers 8.
Antenna (picture B):
--- Unscrew two fixing screws of the front hinge of the
RH side side window. Fit two washers 6 (If not
fitted) and the antenna bracket 5 under the screws
and retighten the screws.
--- Fasten the antenna and pass the wire between the
roof and the edge seal, cut the seal if needed (on
later tractors there is a ready---made hole for the
antenna wire). Slacken, if needed, the roof fixing
screws.
Radio (picture C):
--- Cabs to the end of the year 1993: Open the radio
space on the panel plate and fasten the plate 2.
--- PT94-- cabs: The mountingplate for the radio has
been mounted in the factory.
--- Fit the bracket +radio into the housing according
to the radio instruction book (note locking forks of
the radio bracket).
--- Connect radio supply and earth wires to the con-
nector A2 in the RH side upper corner of the cab
(connector exists in the cab wire loom).
Connect the loadspeaker and antenna wires and
fasten the radio.
