968
Model Code Page
64. Powered front axle
1. 1. 1994
6000--8750 640 8
Differential lock
Picture 5. Differential lock on powered front axle
The front axle differential lock is an optional equipment for all
Mezzo---tractors from the beginning of the year 1994.
The front and rear locks are supplied via the same solenoid
valve (Y1) and both locks are controlled withthe same rocking
switch on the driver’s right. Clutch pressure (1,8 MPa) from
the low pressure circuit.
Differential lock control, see Autocontrol II under code 311,
Autocontrol IV under code 350.
Repair instructions o f the differential lock, see page 644/8.
