Valtra 6350 - Page 237

230
Model Code Page
31. Tractor electrical system
1. 8. 2000
6200--8750 310 80
S y m --- C o d e
bol Component no
M1 Starter motor 3, 167
M2 Fan 55
M3 Windscreen wiper 53
M4 Windscreen washer 51
(M5) Rear window wiper 49
(M6) Rear window washer 48
M7 Floor fan 57
(M8) Water pump 97
(M9) Roof window wiper
P1 Engine temperature meter 16
P2 Fuel gauge 17
P3 Tachometer 18
P4 Running hour meter/AC (Sigma) 19
(P4 Running hour /speed meter (AD instrumentation)) 19
(P5) Clock, PTO---speed, AC, trip, oil temperature (Agroda-
ta--- instrumentation) 101
Q1 Heat/starter switch 4
(Q2) Main switch 3, (167)
R1 Thermostart 5
R4 Cigarette lighter 91
R7 Potentiometer, front PTO, starting speed 161
S1 Switch, head lights 28
S2 Switch, rear working lights 41
S3 Switch, fan 55
S4 Combined switch 25, 34, 52
S5 Switch, front working lights 43
(S6) Switch,rot.warninglight 47
S7 Switch, hazard warning flashers 32
(S8) Switch, air conditioner 54
S9 Starter safety switch 66
S10 Switch, braking lights, right 72
S11 Fuel gauge sender unit 17
S12 Pressure drop indicator, air filter 7
S13 Engine oil press. sender unit 8, 118
S15 Sender unit to parking brake ind. light 12
(S15) Reed relay, parking brake (P) 149
S16 Gearbox temperature sender unit 13
S17 Gearbox oil pressure sender unit 9, 119
S18 Engine temperature sender unit (stop) 16
(S19) Switch, compressor pressure 54
S20 Switch braking lights, left 73
S22 Switch, differential lock 62
(S23) Switch, DPS, selector 139, 140
S24 Switch, DPS disengagement 69
S25 Switch, PTO 75
(S26) Switch, fog light rear 35
(S27) Switch, reverse buzzer 96
S28 Switch, PTO 540 68
S29 Switch, PTO 1000/540E 67
S30 Switch, 4WD 68
S31 Switch, floor fan 57
(S32) Switch, rear window wiper and washer 48
(S33) Change over switch, head lights up 23
(S34) Switch, water pump 97
(S35) Switch, rear steering prevention 94
(S36) Switch, control stop 4
(S44) Indicator light switch, filter 180 bar 11
(S45) Switch, HiShift 115, 142
(S45.1) Extra switch, HiShift 115
(S49) Change over switch, rpm/flow sensor
(S50) Change over switch, speed sensor, tractor/implement
(S53) Indicator light switch, filter, return 10
(S54) Indicator light switch, filter, 18 bar 11
(S59) Switch, roof window washer 49
(S66) Switch, PTO display, front/rear 163
S68 Switch, main currect switch control 168
S y m --- C o d e
bol Component no
V1 Diodes Y1, Y2, Y3, Y4, Y6
V2 Diodes, AC---2
V3 Diodes Y1, Y2, Y3, Y4, Y6 65
(V5) Diodes, HiShift 115
Ground leads
GR1 Rear lights, solenoid valves
GR2 Roof
GR4 Autocontrol
GR5 Cable harness, instr. panel
GR7 Battery
GR8 Headlights
GR9 Cabin
GR10 Electrical stop
X1 9 pin, distribution box
X2 9 pin, distribution box
X3 9 pin, distribution box
X4 9 pin, distribution box
X5 9 pin, distribution box
X6 9 pin, distribution box
X7 9 pin, distribution box
(X8) 2 pin, power socket 92
X9 9 pin, combination control
X10 9 pin, combination control
X11 9 pin, upwards
X12 9 pin, rearwards, right
X13 37 pin, transmission
X14 9 pin, rearwards, left
(X15) 3 pin, air cond., diodes 54
X17 7 pin, trailer socket 32
(X18) 2 pin, rear window washer 48
X19 37 pin, front wall
X20 9 pin, front direction indicator
(X22) 2 pin, rot. roof light 47
X23 3 pin, DPS, extra switches 71
X24 9 pin, upwards
X26 26 pin, instrument left, white
X27 26pin,instr.right,blue
(X29) 2 pin, STOP---alarm (max. 2 W)
X30 9 pin, switches gear levers
X31 2 pin, PTO ---emerg. stop 74
(X32) 1---pin, electric stop 5
(X33) 3 pin, fog light, rear
(X35) 9---pin, Sigma supply
(X36) 3 pin, HiShift, speed ---limit+ supply
(X41) 2 pin, front PTO
(X42) 4 pin, front PTO, supply
(X43) 8 pins, RS ---232 canal
(X45) 9 pin, Fieldmaster, extra equipment
(X46) 7 pins, Fieldmaster socket
(X47) 2 pins, GPS supply, Fieldmaster
(X48) 3 pins, radar, Fieldmaster
(X49) 2 pin, seat
(X50) 3 pin current socket
(X55) 1 pin, Fieldmaster
Y1 Solenoid valve, diff lock 63
Y2 Solenoid valve, PTO 68
Y3 Solenoid valve, 4WD 66
(Y4) Solenoid valve, DPS 69
(Y5) Magnetic switch, compressor, air conditioner 54
(Y6) Solenoid valve, DPS 70
(Y7) Solenoid valve, rear steering prevention 94
(Y8) Solenoid, engine running 4
(Y9) Magnetic clutch, front---PTO 164
(Y13) Solenoid valve, Sigma 113
(Y14) Solenoid valve, HiShift 115
(Y15) Solenoid valve, HiShift, slowing 115
(Y16) Solenoid, cold cranking 3
