62
1. 9. 2002
6250--8950 310 90
Model Code Page
31. Tractor electrical system
S y m --- C o d e
bol Component no
K1 Relay, front working lights 43
K2 Relay, rear working lights 41
(K3) Relay, fog light, rear 35
K4 Auxiliary relay, st arter switch 7
K5 Auxiliary relay, st arter switch 9
K6 Relay, fan III 56
K7 Control relay, 4---wheel brake 71
K9 Relay, interval wiper 52
K10 Direction indicator relay 34
K11 Relay, brake lights/differential lock 64
K13 Control relay, differential lock 65
K14 Starter motor relay 4
K15 Control relay, 4--- wheel drive 70
K17 Relay, electric sto p solenoid, 8950Hi
(K18) Relay, control stop 8
K25 Control relay, upper head lights to working lights
K27 Control relay, 4WD on/off 68
(K29) Relay, back buzzer 147
(K51) Warning light, main switch 191
K52 Auxiliary relay, start allowed 66
K56 Time---delay relay, cab light 46
M1 Starter motor 3
M2 Fan 55
M3 Windscreen wiper 53
M4 Windscreen washer 51
(M5) Rear window wiper 49
(M6) Rear window washer 48
M7 Floor fan 57
(M8) Water pump 97
(M9) Roof window wiper 50
P1 Engine temperature meter 16
P2 Fuel gauge 17
P3 Tachometer 18
P4 Running hour meter 19, 111
P5 Clock, PTO---speed, AC, trip, oil temperature,
speed, (Sigma) (Agroline instrumentation) 102
P6 Display, AC5 133
Q1 Heat/starter switch 4
(Q2) Main switch 3, 196
R1 Thermostart 5
R4 Cigarette lighter 91
R7 Potentiometer, front PTO, starting speed 184
S1 Switch, head lights 28
S2 Switch, rear working lights 41
S3 Switch, fan 55
S4 Combined switch 25,34, 52
S5 Switch, front working lights 43
(S6) Switch,rot.warninglight 47
S7 Switch, hazard warning flashers 32
(S8) Switch, air conditioner 54
S9 Starter safety switch 142
S10 Switch, braking lights, right 72
S11 Fuel gauge sender unit 17
S12 Pressure drop indicator, air filter 7
S13 Engine oil press. sender unit 8, 118
S15 Reed relay, parking brake (P) 149
S16 Gearbox temperature sender unit 13
S17 Gearbox oil pressure sender unit 9, 119
S y m --- C o d e
bol Component no
S18 Engine temperature sender unit (stop) 16
(S19) Switch, compressor pressure 54
S20 Switch braking lights, left 73
S22 Switch, differential lock 61
S23 Extra switch, Delta Power Shift, selector 139, 140
S25 S witch, PTO 75
(S26) Switch, fog light rear 35
(S27) Switch, reverse buzzer
S28 Switch, PTO 540 146
S29 Switch, PTO 1000/540E 147
S30 S witch, 4WD 68
S31 Switch, floor fan 57
(S32) Switch, rear window wiper and washer 48
(S33) Change over switch, head lights up 23
(S34) Switch, water pump 97
(S35) Switch, rear steering prevention 94
(S36) Switch, control stop 4
S37 Switch, Agroline instrumentation, curso r+prog. 103
(S38) Switch, front ---PTO 183
S40 Reed relay, direction forward (F) 146
S41 Reed relay, direction reverse ( R) 149
S42 Door switch, cab light, RH 46
S43 Door switch, cab light, LH 46
(S44) Indicator light switch, filter 180 bar 11
S45 Switches, HiShift 142
(S45.1) Extra switch, HiShift
S47 Switch, DPS, man./auto 144
S51 Switch, DPS---preselection 146
S52 Indicator light switch, parking brake cable 14
S53 Indicator light switch, filter, return 10
(S54) Indicator light switch, filter, 18 bar 11
(S59) Switch, roof window washer 49
S60 Safety switch, se at 142
(S68) Switch, main switch control 196
S76 Traction control on/off 161
S80 Switch, instrumentation, display size setting 103
S83 Switch, trailer hitch light 204
S84 Switch, extra front working lights 200
V1 Diodes Y1, Y2, Y3, Y4, Y6
Ground leads
GR1 Rear lights, solenoid valves
GR2 Roof
GR4 Autocontrol
GR5 Cable harness, instr. panel
GR7 Battery
GR8 Headlights
GR9 Cabin
GR10 Electrical stop
X1 9 pin, distribution box
X2 9 pin, distribution box
X3 9 pin, distribution box
X4 9 pin, distribution box
X5 9 pin, distribution box
X6 9 pin, distribution box
X7 9 pin, distribution box
(X8) 2 pin, current socket 92
X9 9 pin, combination control
X10 9 pin, combination control
X11 9 pin, upwards
X12 9 pin, rearwards, right
X13 37 pin, transmission
X14 9 pin, rearwards, left
(X15) 3 pin, air cond., diodes 54
X17 7 pin, trailer socket 32
