8
Step9. Install aileron servo, elevator servo and rudder
servo onto the fuselage from the nose to tail.
Step10.
Slide the vertical fuselage into the
horizontal fuselage.
Align the tabs from the vertical fuselage into the slots
in the horizontal fuselage.
Adjust the vertical fuselage to make it in the center
line of the horizontal fuselage.
Step11. Use foam safe glue and square to glue the
vertical fuselage and horizontal fuselage together.
Step12. Use a knife to cut a 45 degree bevel on the
glue edges of the zigzag.
Step13. Position the zigzag onto the fuselage as
shown. Start to glue it at the tail and work your way
slowly toward the front of the fuselage.
Section2. Servo Linkage Installation
Step1. Locate the item as shown.
Step2. Use thin CA and heat shrinking tube to connect
the pushrod to the carbon fiber rod.
To Next Page
