SPECIFICATIONS
Input Signal ............................................................... TX: 1 HDMI,1 IR; RX: 1 IR, 1 RJ-45
Input Connector ......................................................... TX: HDMI female, 3.5mm mini jack; RX: 3.5mm mini
jack; RJ-45
Video Signal .............................................................. HDMI1.4
Audio ........................................................................ Digital audio, transmit through HDMI audio
Output ...................................................................... TX: 1 RJ-45, 1 IR; RX: 1 HDMI, 1 IR
Output Connector ...................................................... TX: RJ-45., 3.5mm mini jack; RX: HDMI female
3.5mm mini jack
Video signal ............................................................... HDMI1.4
Transmission Mode ................................................... HDBaseT
Resolution Range ....................................................... 800x600@60Hz~4K×2K
Transmission Distance ................................................ Maximum distance 230 ft. (70 m)
SNR ......................................................................... >70dB@ 100MHz-100M
Bandwidth ................................................................. 10.2Gbps
THD ......................................................................... 0.005%@1KHz
HDMI Standard .......................................................... Support HDMI1.4, and HDCP
Impedance ................................................................ 75Ω
Temperature.............................................................. 0~ 50 degrees C
Reference Humidity .................................................... 10% ~ 90%
Power Supply ............................................................ DC 12V, 1A
Power Consumption ................................................... 9.6W
Weight ..................................................................... 0.28Kg 0.28Kg
HDMI Resolutions ...................................................... 480I, 480P, 576I, 576P, 720P, 1080I, 1080P,
4Kx2K, 1080P 3D
DVI Resolutions ......................................................... 640x480@60Hz, 640x480@72Hz, 640x480@75Hz,
800x600@60Hz, 800x600@72Hz, 800x600@75Hz, 1024x768@60Hz, 1024x768@70Hz,
1024x768@75Hz, 1280x720@60 Hz, 1280x1024@60Hz, 1280x1024@75Hz, 1600x1200@60Hz,
1920x1080@60Hz, 1920x1200@60Hz
Note: HDBaseT Extender supports 4K&1080p 3D HDMI signal, please adopt quality HDMI cables compliant
with HDMI1.4 for reliable transmission when using
PACKAGE CONTENTS
• EVEXHDB1 (TX & RX)
• (1) IR Blaster (TX)
• (1) IR Receiver (RX)
• (1) DC 12V in line power supply
• Mounting Hardware
• Product Manual
