Change function Click this button to change the function for this indicator. The function can
be enabled or used for a system, area, zone or keyswitch.
Deactivation
Calendar Select if the keyswitch module should be limited by calendar.
Mapping gate Select if the keyswitch module should be limited by a mapping gate.
Output
Output x Configure and text the outputs for the keyswitch. See Editing an output on
page231 for more details.
Keyswitch Functions
Centre, Right and
Left Positions
Select the Function that that this keyswitch position will perform and the
relevant Area.
Keyswitch functions are:
l None
l Unset
l Partset A
l Partset B
l Fullset
l Toggle Unset / Fullset
l Toggle Unset / Partset A
l Toggle Unset / Partset B
l All Okay
l Setting authorisation
l Shunt
WARNING: Your system will not comply with EN standards if you enable a keyswitch function to
set the system without a valid PIN being required.
17.10.2.2 Keypads
Editing a Standard Keypad
1. Select Configuration > Hardware > X-Bus > Keypads.
2. Click one of the standard keypad identifying parameters.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the browser
© Vanderbilt 2018 244 A6V10276959-d
11.2018
