Event Logging Options
Comms Status Log all communication availability.
EDP Commands Log all commands executed through EDP.
A/V Events Log when Audio/Video verification events are sent to Receiver.
A/V Streaming Log when Audio/Video live streaming begins.
Keypad Use Log when remote keypad is activated.
17.11.3.3 CEI-ABI Protocol Settings
1. Select Communications > Reporting > CEI-ABI.
The following page will be displayed:
2. Configure the fields as described in the table below.
Enable Tick this box to enable CEI-ABI support.
Connection
mode
l Select Client to connect the panel to the CEI-ABI receiver.
l Select Server to enable the panel to listen for connections.
Server IP If you select Client for Connection mode, enter the TCP/IP address of the
CEI-ABI receiver.
Server Port Enter the IP port for the server.
Physical
address
Enter a physical address for the CEI-ABI on the panel.
Logical
address
Enter a logical address for the CEI-ABI on the panel.
17.11.4 PC Tools
This section covers:
l SPC Connect PRO below
l SPC Manager on the facing page
17.11.4.1 SPC Connect PRO
SPC Connect PRO is a desktop application designed to support the installation and maintenance of SPC
systems. Using SPC Connect PRO, you can create installations and configure them prior to arriving at
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the browser
© Vanderbilt 2018 335 A6V10276959-d
11.2018
