Component Identification and
Description of Operation
IT SERIES Industrial True Sine Wave Inverter Owners Manual
12
4 COMPONENT IDENTIFICATION and DESCRIPTION of OPERATION
Figure 3 Inverter Top View
(1) Top entry for positive DC input cable
(2) Top entry for negative DC input cable
(3) Top entry for Remote Control Terminal Block
