Cabinet Sz 4 (5 – 45 kg/h Models)
55
990
360
20.5"(520)
468
31.1"(790)
55
505
176
6
360
6
152
343
343
70 850
62
237
190
610
810
322
346
190
610
73555
FF
D
Steam Outlets
54 mm
Gland Plate
120 X 120
Gland Plate
120 X 120
Left:
Top View Showing Steam
O/let position
Below: Rear View
showing wall mounting
points.
Left:
Bottom View Showing
“F” (Feed connection) ¾”
BSP male connection for
flexible hose provided
with unit.
“D” (Drain connection)
35 mm pipe.
NB:
Entry hole for gland
plates is approx.
105 mm x 90 mm
For clearance around the unit for ventilation and access see page 7
