Page 26 3001002 Rev. P
Section 16 Specifications
PHYSICAL CHARACTERISTICS
Dimensions:
Height 11.5”(300mm), width 8”(200mm), depth 7”(180mm), excluding IV pole clamp and
gas filters.
Weight:
10.6 lb (4.81 kg) without disposable patient circuit
Circulating Water Volume:
400 ml approx. including delivery tube and cartridge.
Mounting:
Rear mounted clamp fits IV poles up to 1.5”(38mm) diameter.
Gas Connections:
Standard DISS non-interchangeable fittings for medical air and oxygen.
FUSES: (Qty 2) GMA 3A F250 V 5mm x 20mm
SYSTEM REQUIREMENTS
Power:
100-240VAC, 50-60Hz, approx. 200VA during warm up, approx. 80VA in steady state
(depends on flow rate and temperature).
Back-up power:
(Qty 4) 4.8V nickel-metal hydride AA batteries (not user replaceable).
Gas supply:
Medical air and oxygen at inlet pressures between 4 and 85 psi (28-586 KPa).
NOTE: the full range of flows and oxygen percentage is available only if both gases are
present at inlet pressures of at least 40 psi (276 kPa).
Water:
Sterile water in pre-filled sealed container.
PERFORMANCE
Temperature:
Range- 33 to 43°C at exit from the delivery tube, adjustable
Resolution- 1°C
Accuracy- ± 2°C
Warm up time:
± 2°C of 33°C set point < 5 minutes (at ambient 23°C)
Humidification:
Complies with ISO8185-2007 Respiratory tract humidifiers for medical use, paragraph 101
Oxygen percentage:
Range- 21 to 100% O2
Accuracy- ± 2%
Resolution- 1%
NOTE: At 22% & 23% oxygen blend, the delivered oxygen is 21%.
