DS-521
Position STOP:
Engine is not running (position ‘1’)
➢ Used for turning off the running engine.
➢ Putting the machine out of service.
➢ Refuelling
➢ Machine transport
Position MIN:
Engine is running at idle. (position „2“ turtle)
➢ Short work break
Position MAX:
Engine is running at maximum rpm. (position „3“
hare)
➢ Working position
Position CHOKE:
Engine is running. (position „4“)
➢ Cold engine start
Pict. 3: Positions of accelerator lever
Pict. 4: Cutting width
Pict. 5: Lubricating point
Pict. 6: Lubricating point
Pict. 7: Lubricating point
Pict. 8: Lubricating point
Pict. 9: Lubricating point
Pict. 10: Adjustment of the wheel drive tightening pulleys
Pict. 11: Disc drive clutch lever – brake
Pict. 12: V-belt track
Pict. 13: Safety pictogram - Machine wheel drive
Pict. 14: Safety pictogram - Starting up the disc
Pict. 15: Safety pictogram – Combined sticker Location on the machine
Pict. 16: Safety pictogram - Arrow direction of turning
25
