Seek authorised service in case you lack appropriate manual skills.
2.5.4.2 Brake function control and adjustment
Check the automatic brake function after every 10 hours of use. (Current control can be done during operation.) Every time you release
the disk drive clutch lever, the automatic brake must stop the disc within 5 sec.
Do not continue working with the cutter unless you remove the automatic brake defect.
Seek authorised service in case you lack appropriate manual skills.
In case the brake does not stop the cutting disc in the given time span, it is necessary to adjust the brake cable
2
Pict.11,
12
.
Adjusting screw, which tightens the brake cable
2
to the cutter frame
Pict.11
, needs to be screwed in against the direction of the arrow
(towards the frame), so that the axial clearance of the brake cable in the adjusting screw is 1 mm. Check the automatic brake function. If
complete tightening the screw
2
does not offer adequate brake effect, tighten the adjusting screw of the brake cable on the handlebars so
that the axial clearance of the brake cable in the adjusting screw is 1 mm. Check the automatic brake function
59
.
If, after the adjustment
60
, the brake does not work properly, contact an authorised service center.
2.5.5 Service intervals
Activity Before cutting In season Before storage
Engine oil level check yes following the engine user manual yes
Cleaning the engine air filter check every 10 hours yes
Washing - 2x yes
Removal of dirt and cut stand remains - after each cutting yes
Blades sharpening - according to need yes
Check the blades and their placing yes immediate exchange if damaged yes
Cutting disk tightening check yes - yes
Bolted connections tightening check yes every 5 hours yes
Lubrications condition check
Table 6 Table 6
V-belts check - every 20 hours yes
Tab. 7: Service intervals
2.5.6 Problems and solutions
Problem Cause Solution
Cutting disc is not spinning the engine is not running Start the engine
wheel drive clutch lever is not pressed Press the lever
insufficient belt tightening Adjust the tightening pulley
broken belt Exchange the belt with a new one
fallen belt Mount the belt
other defect Visit the service centre
The cutter does not move the engine is not running Start the engine
wheel drive clutch lever is not pressed Press the lever
insufficient belt tightening Adjust both tightening pulleys
broken belt Exchange the belt with a new one
fallen belt Mount the belt
other defect Visit the service centre
Engine does not start there is no petrol in the tank Refuel
petrol feed is closed Open petrol feed
other defect Visit the service centre
Brake does not work there is no axial clearance in the brake cable, the cable is tight Adjust the brake
cam is hard to move Lubricate
brake lining has deteriorated – impossible to adjust the brake Visit the service centre
Impossible to stop the cutter wheel drive pulley is broken Exchange it with a new one
tight cable wire; bended cable Lubricate or exchange cable
tightening pulley does not come back Lubricate
Impossible to stop the cutting disc tightening pulley does not come back Lubricate
59
You may follow opposite instructions. First tighten the screw of the brake cable (towards handlebar rail) on the handlebars so that the axial clearance in the adjusting screw is 1 mm.
60
The condition of the axial clearance of the brake cable in the adjusting screw is met.
