Varian Saturn 2000 GC/MS Pre-Installation Instructions

Space and Weight Requirements
Before arranging for delivery of the Saturn GC/MS to your facility, please make sure that all
passages to the site of installation are at least 91.5 cm (36 in.) wide. Allow additional room for
maneuvering the shipping container around corners and/or through doors.
Table 1 identifies the space and weight requirements of the Saturn GC/MS components. The
Saturn GC/MS is intended to sit on a workbench that is wide enough and deep enough to
accommodate these components, and sturdy enough to support their combined weight. Varian
recommends the layout shown in Figure 1, and the space allowances in Table 2.
Table 1 Dimensions and Weights of the Saturn System Components
Height Width Depth Weight
Instrument in. cm in. cm in. cm lb. kg
Saturn MS
1
18 46 12 30 22 56 66 30
3900 GC 18 46 13 32 22 56 51 23
CP-3800 GC 20 51 26 66 22 56 95 43
CP-8400 AutoSampler / CP-8410
AutoInjector (sits on top of GC)
16 41 9 23 18 46 20 9
CP-8200 AutoSampler (sits on top
of GC)
20 51 6 16 16 41 24 11
Tekmar 3000 Purge and Trap 19 48 9 23 18 46 37 17
Archon Purge and Trap AutoSampler 17 43 22 55 21 53 80 36
Tekmar ALS-2016 27 69 15 38 15 38 35 16
Genesis Headspace AutoSampler 22 56 28 71 18 46 110 50
Saturn Chromatography Workstation
2
(computer with monitor, approximate
values)
20 51 17 43 21 53 35 16
1
Allow an additional 76 cm (30 in.) of vertical clearance above the mass spectrometer module to allow for
routine maintenance.
2
Allow an additional 20 cm x 20 cm (8 in. x 8 in.) of bench space beside the keyboard for mouse operation.
Table 2 Spatial Set-up Requirements for Saturn GC/MS
Recommendations Purpose Recommended Distance
Allow adequate space to the right of
the GC/MS.
Permit access to the transfer line
and turbomolecular pump. See
Figure 1.
~ 61 cm (24 in.)
Allow adequate space behind the
system.
Provide clear space for air
circulation, gas lines, and electrical
connections.
15 to 30 cm (6 to 12 in.)
Allow vertical clearance above the
GC/MS.
Dissipate heat and allow for routine
maintenance.
≥102 cm (4 in.)
Allow additional bench space beside
the Workstation keyboard
Enable mouse operation. 20 cm x 20 cm (8 in. x 8 in.)
03-914629-00:7 2 of 9 Saturn 2000 GC/MS Pre-installation Instructions
