VARMEC RCV 252 - Trägheitsmoment

86
MOMENTI D'INERZIA / MOMENTS OF INERTIA / TRÄGHEITSMOMENT
MOMENTS D' INERTIE / MOMENTOS DE INERCIA / MOMENTO DE INERCIA
Il momento d'inerzia Jr [Kgcm
2
] indicato
nelle tabelle è riferito all'albero veloce
del riduttore.
Le moment d’inertie Jr [Kgcm
2
] indiquée
dans les tableaux se réfère à l’arbre
d’entrée du reducteur.
The moment of inertia Jr [Kgcm
2
] shown
in these tables refers to the gear reduc-
er’s input shaft.
El momento de inercia Jr [Kgcm
2
]
indicado en las tablas se reere al eje
rápido (entrada) del reductor.
Das in den Tabellen angegebene Träg-
heitsmoment Jr [Kgcm
2
] ist abhängig
von der Antriebswelle.
O momento de inercia Jr [Kgcm
2
] indi-
cada na tabela é referido ao eixo veloz
do ridutor.
14
141
i IEC 56 IEC 63 IEC 71 IEC 80
1.29 0.837 0.834 0.824 0.990 0.865
2.33 0.476 0.473 0.463 0.629 0.504
2.79 0.402 0.399 0.389 0.555 0.429
3.40 0.342 0.339 0.330 0.496 0.369
4.24 0.292 0.290 0.280 0.446 0.319
4.79 0.266 0.264 0.254 0.420 0.293
5.47 0.243 0.240 0.231 0.396 0.270
7.46 0.208 0.206 0.196 0.362 0.235
8.17 0.199 0.196 0.186 0.352 0.226
191
i IEC 56 IEC 63 IEC 71 IEC 80 IEC 90
1.26 1.417 1.414 1.404 1.964 2.052 2.075
2.23 0.783 0.780 0.770 1.330 1.838 1.441
2.73 0.637 0.634 0.624 1.184 1.784 1.295
3.22 0.509 0.506 0.497 1.050 1.634 1.165
4.11 0.432 0.429 0.419 0.972 1.651 1.078
4.71 0.377 0.374 0.365 0.917 1.591 1.032
5.47 0.331 0.328 0.318 0.871 1.525 0.986
7.82 0.252 0.249 0.240 0.793 1.360 0.908
9.78 0.214 0.212 0.202 0.755 1.204 0.870
241
i IEC 63 IEC 71 IEC 80 IEC 90 IEC 100-112
1.26 2.064 2.018 1.964 1.834 3.399 2.075
2.23 1.430 1.384 1.330 1.200 2.765 1.441
2.73 1.284 1.238 1.184 1.054 2.619 1.295
3.22 1.115 1.107 1.050 0.927 1.165
4.11 1.038 1.029 0.972 0.849 1.078
4.71 0.983 0.975 0.917 0.794 1.032
5.47 0.937 0.928 0.871 0.748 0.986
7.82 0.858 0.850 0.793 0.670 0.908
9.78 0.821 0.812 0.755 0.632 0.870
281
i IEC 71 IEC 80 IEC 90 IEC 100-112 IEC 132
1.14 8.251 8.220 8.066 7.829 11.825 7.538
1.56 6.308 6.276 6.122 5.886 9.881 5.594
2.29 4.823 4.792 4.638 4.401 8.397 4.110
2.83 4.173 4.122 3.960 3.759 3.483
3.38 3.829 3.778 3.617 3.416 3.102
3.84 3.625 3.574 3.412 3.211 2.897
4.41 3.439 3.388 3.226 3.025 2.711
5.57 3.193 3.142 2.980 2.779 2.465
7.36 2.987 2.936 2.775 2.574 2.260
381
i IEC 80 IEC 90 IEC 100-112 IEC 132
1.63 17.530 18.297 17.306 17.216 13.890
2.29 14.171 14.973 13.950 13.935 10.512
3.00 12.398 13.200 12.176 12.161 8.738
3.38 11.795 12.596 11.573 11.558 8.135
4.11 10.989 11.791 10.767 10.752 7.329
4.75 10.688 10.671 10.467 10.451 7.038
5.57 10.084 10.068 9.863 9.848 6.434
7.36 9.531 9.514 9.310 9.294 5.881
10.40 9.116 9.089 8.894 5.459
RCV
CV
Jr
[Kgcm
2
]
