VARMEC RCV 252 - Page 89

89
253
i IEC 56 IEC 63 IEC 71
60.1 0.503 0.500 0.490 0.518
69.6 0.296 0.294 0.284 0.313
82.0 0.296 0.293 0.284 0.313
89.7 0.296 0.293 0.284 0.312
109.1 0.296 0.293 0.283 0.312
122.5 0.209 0.206 0.197 0.226
144.4 0.209 0.206 0.197 0.225
157.9 0.209 0.206 0.197 0.225
192.1 0.209 0.206 0.197 0.225
253A
i IEC 56 IEC 63 IEC 71
63.09 0.232 0.229 0.219 0.248
74.36 0.225 0.222 0.213 0.241
81.29 0.225 0.222 0.213 0.241
98.94 0.224 0.222 0.212 0.241
108.83 0.224 0.222 0.212 0.241
120.15 0.213 0.211 0.201 0.230
141.61 0.213 0.210 0.201 0.230
154.81 0.213 0.210 0.201 0.229
188.42 0.213 0.210 0.201 0.229
207.26 0.213 0.210 0.201 0.229
302
i IEC 71 IEC 80 IEC 90 IEC 100-112 IEC 132
3.74 8.242 8.210 8.056 7.820 11.816 7.528
4.56 7.868 7.837 7.683 7.447 11.442 7.155
5.11 6.303 6.271 6.117 5.881 9.876 5.589
6.22 6.102 6.071 5.917 5.681 9.676 5.389
6.93 6.013 5.981 5.827 5.591 9.586 5.299
7.78 5.930 5.899 5.745 5.509 9.504 5.217
7.51 4.821 4.789 4.635 4.399 8.394 4.107
9.14 4.728 4.696 4.542 4.306 8.302 4.014
10.18 4.686 4.655 4.501 4.265 8.260 3.973
11.43 4.648 4.617 4.463 4.227 8.222 3.935
12.62 3.636 3.585 3.423 3.222 2.908
15.37 3.603 3.552 3.390 3.189 2.875
17.11 3.588 3.537 3.375 3.175 2.861
19.21 3.575 3.524 3.362 3.161 2.847
24.19 2.987 2.936 2.774 2.574 2.260
29.45 2.978 2.927 2.765 2.565 2.251
32.80 2.974 2.923 2.761 2.561 2.247
36.82 2.971 2.920 2.758 2.557 2.243
RCV
CV
Jr
[Kgcm
2
]
MOMENTI D'INERZIA / MOMENTS OF INERTIA / TRÄGHEITSMOMENT
MOMENTS D' INERTIE / MOMENTOS DE INERCIA / MOMENTO DE INERCIA
14
302A
i IEC 63 IEC 71 IEC 80 IEC 90 IEC 100-112
3.78 4,584 4,530 4,411 6,020 5,743
4.40 4,300 4,247 4,128 5,736 5,460
5.20 4,046 3,992 3,873 5,482 5,205
6.27 3,818 3,764 3,645 5,254 4,977
7.76 3,616 3,563 3,444 5,052 4,776
8.75 1,853 1,799 1,680 3,323 2,999
10.18 1,800 1,746 1,627 3,270 2,946
12.03 1,752 1,699 1,580 3,222 2,899
14.50 1,710 1,656 1,537 3,179 2,856
17.95 1,672 1,618 1,499 3,142 2,818
19.58 1,062 1,009 0,890 2,532 2,209
22.80 1,052 0,998 0,879 2,521 2,198
26.94 1,042 0,989 0,869 2,512 2,188
32.45 1,034 0,980 0,861 2,503 2,180
40.18 1,026 0,973 0,853 2,496 2,172
44.06 0,844 0,836 0,779 0,656 2,298 1,974
46.59 0,913 0,905 0,848 0,725 2,367 2,043
53.08 0,841 0,832 0,776 0,653 2,294 1,971
57.69 0,909 0,901 0,845 0,722 2,363 2,040
65.72 0,838 0,830 0,773 0,650 2,292 1,968
