VARMEC RCV 252 - Page 92

92
RCV
CV
Jr
[Kgcm
2
]
MOMENTI D'INERZIA / MOMENTS OF INERTIA / TRÄGHEITSMOMENT
MOMENTS D' INERTIE / MOMENTOS DE INERCIA / MOMENTO DE INERCIA
14
552
i IEC 90 IEC 100-112 IEC 132 IEC 160 IEC 180
2.78 46.178 43.304 43.288 67.026 64.949 53.019
3.17 41.727 38.853 38.837 62.575 60.499 48.568
3.68 33.412 30.537 30.521 54.260 52.183 40.253
4.16 38.568 35.694 35.678 59.416 57.339 45.409
4.57 36.987 34.112 34.096 57.835 55.758 43.827
5.50 29.052 26.177 26.161 49.900 47.823 35.892
6.03 28.145 25.271 25.255 48.993 46.916 34.986
7.39 26.865 23.991 23.975 47.713 45.636 33.706
8.39 17.357 16.335 16.320 38.205 36.102 24.132
9.49 15.281 14.259 14.244 36.129 34.025 22.056
11.00 16.905 15.883 15.868 37.753 35.650 23.680
12.07 16.678 15.657 15.641 37.526 35.423 23.454
14.19 14.626 13.604 13.589 35.474 33.370 21.401
15.56 14.489 13.468 13.452 35.337 33.234 21.265
19.06 14.297 13.275 13.260 35.145 33.042 21.072
22.74 11.125 10.920 10.904 32.807 18.750
24.94 11.072 10.867 10.851 32.754 18.697
30.55 10.997 10.792 10.777 32.679 18.622
35.01 9.815 9.610 9.594 31.497 17.440
38.40 9.792 9.587 9.572 31.475 17.417
47.04 9.761 9.556 9.540 31.443 17.386
53.46 9.254 9.060 16.895
65.48 9.238 9.043 16.879
553
i IEC 80 IEC 90 IEC 100-112 IEC 132
70.22 10.693 10.677 10.472 10.457 7.043
88.88 9.539 9.523 9.318 9.302 5.889
108.86 9.533 9.517 9.312 9.297 5.883
118.46 10.482 10.466 10.261 10.246 6.832
125.58 10.781 10.765 10.560 10.545 7.131
145.09 10.479 10.463 10.258 10.242 6.829
170.18 9.932 9.916 9.711 9.696 6.282
183.64 9.445 9.429 9.224 9.209 5.795
224.93 9.444 9.428 9.223 9.207 5.794
259.37 9.073 9.046 8.851 5.416
317.67 9.072 9.045 8.851 5.415
582
i IEC 90 IEC 100-112 IEC 132 IEC 160 IEC 180
4.64 68.914 68.929 68.914 91.232 89.272 77.225
5.04 66.635 66.650 66.635 88.953 86.993 74.946
6.03 178.890 178.905 178.890 201.208 199.248 187.200
7.38 58.590 58.604 58.590 80.908 78.948 66.900
8.61 33.297 33.311 33.297 55.614 53.654 41.607
9.36 32.636 32.650 32.636 54.954 52.994 40.946
11.20 31.409 31.424 31.409 53.727 51.767 39.719
13.71 30.303 30.318 30.303 52.621 50.661 38.614
15.03 19.450 19.465 19.450 41.768 39.232 27.263
16.34 19.233 19.248 19.233 41.551 39.015 27.046
19.55 18.831 18.845 18.831 41.148 38.612 26.643
23.93 18.468 18.482 18.468 40.785 38.249 26.280
24.99 13.387 13.182 13.167 35.070 21.012
27.16 13.309 13.104 13.089 34.992 20.934
30.24 12.620 12.415 12.400 34.303 20.245
32.50 13.163 12.958 12.943 34.846 20.788
36.18 12.502 12.297 12.282 34.185 20.127
39.79 13.032 12.827 12.812 34.715 20.657
44.29 12.396 12.191 12.176 34.079 20.021
