Important: Damages caused by the disregard of this user manual are not subject to
warranty. The dealer will not accept liability for any resulting defects or
problems. Make sure the electrical connection is carried out by qualified
personnel. All electrical and mechanical connections have to be carried out
according to the European safety standards.
2. Technical Information
- RGBW LEDs with 10W Power
- DMX Mode (4Ch)
- Sound to light mode via internal mic
- Digital display for addressing and functions
- Power and DMX can be daisy chained
3. DMX Mode
To use the DMX Mode you have to adjust the address first, as described a few articles below. The
item needs 4 channels, which you can adjust by using your faders of your DMX console. You can
adjust as follows:
3.1. DMX chart
Channel
Value
Function
1
1 – 16
17 – 33
34 – 50
51 – 67
68 – 84
85 – 101
102 – 118
119 – 135
136 – 152
153 – 169
170 – 186
187 – 203
204 – 220
221 – 237
238 – 255
Color 1
Color 2
Color 3
Color 4
Color 5
Color 6
Color 7
Color 8
Color 9
Color 10
Color 11
Color 12
Color 13
Color 14
Color 15
2
0 – 9
10 – 120
121 – 134
135 – 245
246 – 249
250 – 255
No Rotation
Clockwise rotation slow to fast
no Rotation
counter clockwise slow to fast
no Rotation
Sound To Light Rotation
