www.vax.co.uk
12
how to clean / accessories
To remove hose: Squeeze latches (C) on top and bottom of
hose. Remove hose from port. Close door.
Remove solution tube from solution connection port by
pulling the connector outwards (Fig. 5/10).
6. Accessories
SpinScrub hand tool
The SpinScrub™ hand tool has rotating brushes to agitate
spots and stains. It is stored behind the tool door located
on the front of the cleaner. To remove the tool, open tool
door (Fig. 6/1).
Pull tool down and outward. To reposition the tool, reverse
this procedure (Fig. 6/2).
How To Reattach Tool Cover
The tool cover is designed with a breakaway feature which
allows it to snap free if it is pushed open too far.
To reattach, align hinges of cover with holes on sides of
tool storage area. Snap door into place (Fig. 6/3).
Fig.5/9
Fig.5/10
C
B
Fig.6/1
Fig.6/2
Fig.6/3
