IMU04 LED Colour Power Coms
Red Initial boot up phase No coms
Orange
Temperature checks. If temperature
outside optimum operation range,
LED will remain orange.
Using IMU integration, inertial data
being sent to host VBOX via RS232.
Green Fully operational.
Inertial data being sent to host
system via CAN.
