LVP605 User’s Manual
---------------------------------------------------------------------------------------------------
LED VIDEO PROCESSOR
13
1. Enter Setup of LVP605
Enter setup: While in operation mode (make sure that PIP mode
and Mosaic mode have been switched off), press “Setup” button, then
press the knob(（”Save” key）, LVP605 will enter No.1 setup item.
Exit setup: press “Setup” button while in setup mode, LVP605 will
directly exit setup.
After LVP605 enters setup mode, the knobs and 3 buttons in setup
area will respectively have the functions as described in table below:
Name Functions
Knob
Speed of The step value in proportion to the
Category Items
1 Language 1 Language 语言
2 Output image setup 2
Out Format
3
Out_Hori_Width
4
Out_ Hori _Start
5
Out_Vert_Height
6
Out_Vert_Start
3 text overlay setup 7
Text Mode
8
Threshold Red
9
Threshold Green
10
Threshold Blue
4 Brightness/Color
Contrast/Definition
setup
11
Brightness
12
Contrast
13
Saturation
14
Sharpness
5 Audio configuration 15
Audio1 Config
16
Audio2 Config
6 Hot spare 17
Hot spare < V1V3>
18
Hot spare < V2S-Video >
19
Hot spare < HDMIDVI>
20
Hot spare <VGA1VGA2>
21
Device ID
9 Factory district Setup 22
ADC Calibration
23
De interlace
24
Device init
