Vdwall LVP605 - Front Panel Operations; Front Panel Diagram

LVP605 User’s Manual
---------------------------------------------------------------------------------------------------
LED VIDEO PROCESSOR
7
IV. Frontal panel operations
1. Diagram of frontal panel
1） Input selecting buttons (V1, V2, V3, S-Video, DVI, VGA1, VGA2, YPbPr,
EXT.):
They are used to select input signals
2） Setup buttons (Setup, Save, ↑,↓,←,→)
They are used to set the image output parameters of the processor.
3 2
1
4 6 5
8
10
9
7
