LVP605 User’s Manual
---------------------------------------------------------------------------------------------------
LED VIDEO PROCESSOR
6
recommended to use this port when
operating and setting LVP605).
DVI OUT1 /
DVI OUT2
2 same DVI digital graphic signal output,
it can be connected with external LED
transmission card or LED transmission
box
SDI / HDSDI（OUT） 1-channel digital video signal loop output
DVI Loop OUT
1-channel computer DVI digital signal loop
output
4） Audio Output (AUDIO OUT)
Corresponds to the selected video input signal, output this
channel audio input signals.
5） Signals of other ports
RS232 serial communication port
3. Connection diagram
