LVP605 User’s Manual
---------------------------------------------------------------------------------------------------
LED VIDEO PROCESSOR
8
3） VGA auto adjustment (Auto)
To automatically adjust VGA input signals
4） Cut / Fade switching mode (C/F):
It is used to select signal switching effects, including seamlessly
switching (CUT) and 0.5s, 1.0s and 1.5s Fade in / Fade out.
5） PC signal bypass output (Bypass):
It is used to switch full screen/partial screen display of PC signals, and
the indicator will indicate the status of current input signal.
6） Info:
It is used to display current settings and information of processor
7） PIP/POP buttons (ON/OFF,M1，M2，M3，M4):
ON/OFF: to turn on/off PIP/POP functions, when the indicator is on,
you can select any signal coming from different groups or current signal as
PIP/POP by using input selecting buttons.
M1，M2，M3，M4: used to set or switch PIP/POP modes.
8) Mosaic
It is used to turn ON/OFF multi-machine cascade mosaic function. The
indicator indicates current splicing status.
9) Freeze
It is used to turn ON/OFF screen freezing function.
10) Text
It is used to add Text, company logo or animation.
2. Button instructions (operation mode):
There are 25 buttons on the frontal panel of LVP605, all these buttons
will be operable after start. they have the following functions as
described below:
1) Select input video source
Port name Description
V1、V2、V3 3-channel PAL/NTSC composite video input
S-Video
1-channel PAL/NTSC S-video input
YPbPr
1-channel component HD signal input
VGA1、VGA2 2-channel computer analog signal input
DVI
1-channel computer DVI digital signal input
HDMI
1-channel HDMI digital HD signal input
EXT.
1-channel extended signal input（such as SDI/HDSDI）
Switch audio input while operating above buttons; select the audio
signal input from corresponding video input to output it through Audio
OUT.
After selecting input signals, the input signal source you
