LVP605 User’s Manual
---------------------------------------------------------------------------------------------------
LED VIDEO PROCESSOR
18
Caution: (1). In order to ensure output images in complete gray, the
output parameters are usually set as default values ！
(2). The color parameters only apply to V1、V2、V3、S-Video、
YPbPr、SDI and HDMI signals.
6. Audio configurations
LVP605 supports 3-channel stereo audio switch. Of which, 3
channels are DVI (only available when the input signals are HDMI
signals), HDMI and SDI audios,, the other 2 channels are AD1,
AD2 external input audio. AD1 and AD2 can be mapped to the any
one of all video inputs, and will be switched synchronous to the
selection of video input signals.
If DVI( or SDI, HDMI) is configured as external input audio, when
audio signal is switched to DVI( or SDI, HDMI), external audio will be
chosen as input signals, otherwise the audio signals contained in
DVI( or SDI, HDMI) signals will be chosen as input signals.
Item
No.
Description Definition
23
Audio1 Config Audio configuration option for
AD1 port
24
Audio2 Config Audio configuration option for
AD2 port
Notes: AD1, AD2 can’t be allocated to the video input
signals in the same channel!
7. Hot Spare setup
LVP605 supports hot spare of input signals, that is to say, once the
current input signals are lost, the processor will automatically switch to
backup input signals at once, so as to avoid image interruption caused
by the fault of signal source.
Item Description
17
Hot spare < V1V3>
18
Hot spare < V2S-Video >
19
Hot spare < HDMIDVI>
20
Hot spare <VGA1VGA2>
